22 trillion parameters in Python

This year, I decided to be lazy and do Advent of Code in Python. I am very comfortable in Python and didn't want to fight the language as well as the puzzles for once. For that reason, it's the first time that I actually completed almost all the puzzles.

I originally used a pre-trained neural net to solve Day 24. By the time I understood how the problem works, there was no programming left to do. But then I found out about a clever general solution and decided to try to implement it myself.

If you don't know about Advent of Code...

Advent of Code is a programming game that runs every year for the 25 days of Advent. You're given a two-part puzzle every day. Usually, part 1 is the easier version and part 2 is a much harder variant reusing the same input.

If you don't know about 2021 day 24...

Day 24 defines a very simple computer, or ALU. It has four integer registers and a bunch of basic instructions: add, mul, div, mod, eql. There are no jumps, no loops, so it's nothing more than a calculator. The instruction inp reads one digit of a 14-digit input.

The puzzle is a program for this computer that does some calculation. This calculation sometimes ends with a zero result. The goal is to find the smallest and largest 14-digit number that causes the result to be zero.

Trying the calculation for all possible 14-digit numbers would take a lot of time -- even with digit 0 disallowed, there are 9^14 = 22 trillion possibilities. The standard solution is to read the puzzle program, understand what it calculates, and use this knowledge to reduce the search space.

If you don't know about the brute-force solution...

I learned about Matt Keeter's solution from Reddit. Unlike the standard approach, this solution is general: it can solve any program, not just the one from the puzzle.

The basic idea is, instead of trying the full calculation 22 trillion times, we can keep track of what the possible states of the computer are at any given step.

At start, there is only one possible state: all registers are zero. The arithmetic instructions only convert the state into another state. The only way to create new states is via the inp instruction, which loads a new digit.

So for example, this one-line program:

inp x

will result in nine different possible states:

x: 1, y: 0, z: 0, w: 0
x: 2, y: 0, z: 0, w: 0
x: 3, y: 0, z: 0, w: 0
x: 4, y: 0, z: 0, w: 0
x: 5, y: 0, z: 0, w: 0
x: 6, y: 0, z: 0, w: 0
x: 7, y: 0, z: 0, w: 0
x: 8, y: 0, z: 0, w: 0
x: 9, y: 0, z: 0, w: 0

Another thing to notice is that some instructions can reduce the number of possible states. In the example above, the instruction mul x 0 will collapse the nine different states back into one: whatever was previously in x, there is now a zero.

If the puzzle program behaves at least somewhat nicely, we will never reach 22 trillion states. Hopefully, the total number of states is going to be manageable.

To get the puzzle solution, we just need to keep track of what was the largest and smallest number that got us to some state; one of those will be the answer.

The algorithm

Here is a high-level outline of how the solution will work:

1. Read the next instruction.
2. If it is anything else than inp, execute it on all currently tracked states.
3. If it is inp:
   1. Deduplicate states: identify states that are the same and collapse them into one, keeping the minimum and the maximum that got us there.
   2. Make 9 copies of each state. Set the input digit to be different in each copy.
4. Repeat until end of program.

Getting ready

Let's set up the basics.

We need a data structure to represent one state of the computer:

REGISTERS = "xyzw"

class ALUState:
    def __init__(self):
        self.regs = {reg: 0 for reg in REGISTERS}
        self.min = 0
        self.max = 0

We need an instruction table. We're going to be somewhat smart from the start: instead of having a bunch of if/elif branches for every instruction, we will save a function that performs the operation we want. A lot of those live in the built-in operator module.

The function operator.eq is a little interesting: it takes two integers and returns a boolean, but we want 0 or 1 as the result. But it just so happens that in Python, True == 1 and False == 0.

import operator

INSTRUCTIONS = {
    "add": operator.add,
    "mul": operator.mul,
    "div": operator.ifloordiv,
    "mod": operator.mod,
    "eql": operator.eq,
}

Now, let's implement a "non-deterministic ALU" -- a computer that, essentially, is in all possible states at once.

class NonDeterministicALU:
    def __init__(self):
        # at start, we only have one all-zero state
        self.states = [ALUState()]

    def run(self, program):
        """Run whole program."""
        for line in program.splitlines():
            self.execute(line)

    def find_puzzle_answer(self):
        """Find the smallest and largest number that got us
        to a state with zero."""
        zero_states = (state for state in self.states
                       if state.regs["z"] == 0)
        result_min = 10 ** 15  # all 14-digit inputs are smaller
        result_max = 0         # all 14-digit inputs are larger
        for state in zero_states:
            # find minimum and maximum in one pass
            result_min = min(result_min, state.min)
            result_max = max(result_max, state.max)
        return result_min, result_max

    def execute(self, line):
        """Execute one line of the program."""
        if line.startswith("inp"):
            # inp is handled separately
            self.execute_input(line)
            return

        # split into instruction, destination register and source
        instr, dest, src = line.split()
        instr_func = INSTRUCTIONS[instr]
        if src in REGISTERS:
            # src can either be one of x, y, z, w, or an integer
            # literal value. We expect a lot of states, so we don't
            # want to do "if src in REGISTERS" every time. So we
            # do it ahead of time and call the appropriate function.
            self.execute_register(instr_func, dest, src)
        else:
            self.execute_literal(instr_func, dest, int(src))

    def execute_register(self, instr_func, dest, src):
        """Execute an instruction that takes a register as source."""
        for state in self.states:
            # call the `instr_func` on two registers
            # assign the result to dest
            state.regs[dest] = instr_func(state.regs[dest],
                                          state.regs[src])

    def execute_literal(self, instr_func, dest, val):
        """Execute an instruction that takes a literal value."""
        for state in self.states:
            # call the `instr_func` on a register and value
            state.regs[dest] = instr_func(state.regs[dest], val)

Let's look at the execute_input() method separately. By itself, it is very simple: call the deduplication step, then call the expansion step.

    def execute_input(self, line):
        """Execute the `inp` instruction."""
        instr, dest = line.split()
        assert instr == "inp"
        assert dest in REGISTERS
        # first, reduce the number of states by deduplication
        self.deduplicate()
        # second, make a copy of all states and set the input digit
        self.expand_states_into(dest)

We will deduplicate via a dict. The key is a tuple of register values, and the value is the first such state that we found.

    def deduplicate(self):
        known_states = {}
        new_states = []
        for state in self.states:
            key = tuple(state.regs.values())
            if key in known_states:
                self.update_minmax(known_states[key], state)
            else:
                known_states[key] = state
                new_states.append(state)
        self.states = new_states

    @staticmethod
    def update_minmax(state1, state2):
        state1.min = min(state1.min, state2.min)
        state1.max = max(state1.max, state2.max)

To expand the states, we will only make 8 copies of each, and modify the last one in-place. This is also why we can't use for state in self.states directly: we will be adding states in the for-loop, so we would never exit.

    def expand_states_into(self, dest):
        for i in range(len(self.states)):
            for digit in range(2, 10):
                # digits 2 to 9
                new_state = deepcopy(self.states[i])
                self.set_digit(new_state, dest, digit)
                self.states.append(new_state)
            # digit 1
            self.set_digit(self.states[i], dest, 1)

    @staticmethod
    def set_digit(state, dest, digit):
        state.regs[dest] = digit
        state.min = state.min * 10 + digit
        state.max = state.max * 10 + digit

The set_digit() step increases the length of the current minimums and maximums. If we already executed three inp instructions, our minimums and maximum are 3-digit numbers. Another inp must increase it to a 4-digit one, by adding the new digit to the right.

This also means that we first need to make the copies and then modify the original -- otherwise, the copies would get two more digits instead of one.

Now the runner itself:

from pathlib import Path

INPUT_FILE = Path("input.txt")
alu = NonDeterministicALU()
alu.run(INPUT_FILE.read_text())

result_min, result_max = alu.find_puzzle_answer()
print("Minimum:", result_min)
print("Maximum:", result_max)

Off the screen, I'll add some timing information (complete source) ... and

Let's run it!

% python trillion.py
=== digit 1 ===
deduplication: 0.000 s
expansion: 0.000 s
continuing with 9 states
=== digit 2 ===
deduplication: 0.000 s
expansion: 0.001 s
continuing with 81 states
=== digit 3 ===
deduplication: 0.000 s
expansion: 0.011 s
continuing with 729 states
=== digit 4 ===
deduplication: 0.001 s
expansion: 0.081 s
continuing with 6561 states
=== digit 5 ===
deduplication: 0.008 s
expansion: 0.102 s
continuing with 8748 states
=== digit 6 ===
deduplication: 0.006 s
expansion: 0.732 s
continuing with 65610 states

Cool! Going nice!

=== digit 7 ===
deduplication: 0.061 s
expansion: 7.238 s
continuing with 590490 states
=== digit 8 ===
deduplication: 0.555 s
expansion: 8.526 s
continuing with 721710 states
=== digit 9 ===
deduplication: 0.594 s
expansion: 77.458 s
continuing with 5878656 states

...okay...

=== digit 10 ===
deduplication: 5.064 s
[1]    220471 killed     python trillion.py

What happened is I ran out of RAM. My laptop only has 16 GB, plus 1 GB swap. Even after shutting down the browser and vscode, it was not enough.

I briefly toyed with increasing swap space, but it turns out that as soon as the calculation overflows to swap, it grinds to a halt. It might not finish in time for the next Advent.

We need to reduce RAM usage somehow.

Reducing RAM usage

First idea: the ALU state is just six numbers. We don't need a dict and a class to represent six numbers, we could use a simple list.

Each state will be represented by a list of six numbers. Indices 0 to 3 represent registers x to w. Index 4 is minimum and index 5 is maximum.

# instead of
state.regs[dest] = value
state.min = some_minimum
# do
dest_reg = REGISTERS.index[dest]
state[dest_reg] = value
state[STATE_MIN] = some_minimum

Not much more interesting beyond that, you can see the code for yourself.

Trying again:

...
=== digit 7 ===
deduplication: 0.043 s
expansion: 0.553 s
continuing with 590490 states
=== digit 8 ===
deduplication: 0.472 s
expansion: 0.745 s
continuing with 721710 states
=== digit 9 ===
deduplication: 0.480 s
expansion: 6.421 s
continuing with 5878656 states
=== digit 10 ===
deduplication: 4.515 s
expansion: 58.542 s
continuing with 52907904 states

Better!

=== digit 11 ===
[1]    225074 killed     python trillion-with-list.py

Killed before deduplication finished! Oh no! The list of states is now so large that we can't even construct the deduplicating dict.

Or maybe the list of new_states is the problem... Let's try a tweak.

    def deduplicate(self):
        known_states = {}
        cursor = 0
        for current in range(len(self.states)):
            state = self.states[current]
            key = tuple(state[:4])
            if key in known_states:
                self.update_minmax(known_states[key], state)
            else:
                known_states[key] = state
                self.states[cursor] = state
                cursor += 1
        del self.states[cursor:]

Instead of creating a new list of states, we will reuse the existing one. cursor points to the first spot that we can replace. At start, the "replace" will be a no-op, we will be replacing the state with itself. In all subsequent cases, we are replacing something that was either (a) already moved to the front, or (b) ignored because it is a duplicate state.

At the end, we delete the rest of the list, so that only the copied-over states remain.

Trying...

=== digit 11 ===
deduplication: 46.264 s
[1]    226107 killed     python trillion-list-dedup.py

Well look at that, it helped!

A little.

First of all, the deduplication now takes 46 seconds. Second, we are at the limit anyway, the expansion step won't finish.

What's smaller than a list?

A list of six numbers should be small. But it really isn't. For one, Python's lists can store any object. This means that the list actually stores pointers. For every item, you need to store 8-byte pointer, plus the item object itself.

Python's numbers are also objects. Even if a 64-bit number only takes 64 bits (8 bytes) of memory, there is at least 8 more bytes indicating object type. There is some sort of optimization for "small numbers", but we can't be sure that it applies for our usecase.

(This is true for CPython, the "official" interpreter from python.org. It just might turn out that using, e.g., PyPy, our RAM requirements would be lower from the get-go and we could just stop here.)

Enter array. It's an "efficient array of numeric values". Which is exactly what we need here.

Let's try it. The change is basically two lines:

from array import array

class NonDeterministicALU:
    def __init__(self):
        # instead of:
        # self.states = [[0] * 6]
        # use:
        self.states = [array('q', [0] * 6)]

Using 'q' for the data type, which is a "signed long long", or, in human speak, a 64-bit integer with support for negative values. We don't know how big the numbers get during the computation, but we do know that negative values are allowed, so I'm picking the largest number type that I have. It takes 8 bytes of memory, but can never grow beyond that.

Running the program again...

=== digit 10 ===
deduplication: 5.544 s
expansion: 37.640 s
continuing with 52907904 states

Twice as fast as before, half as much RAM consumed. We're now at 6 GB. The previous version consumed 13 GB for digit 10.

=== digit 11 ===
deduplication: 58.994 s
expansion: 65.493 s
continuing with 88179840 states
=== digit 12 ===
deduplication: 98.897 s
expansion: 71.800 s
continuing with 101702790 states
=== digit 13 ===
deduplication: 107.779 s
expansion: 59.891 s
continuing with 95866416 states
=== digit 14 ===
deduplication: 102.136 s
expansion: 68.294 s
continuing with 107811162 states
Computation finished in 1623.035 s
Minimum: 41171183141291
Maximum: 91398299697996

...and done.

RAM usage peaked around 14 GB. Fortunately, it turns out that the number of states stops growing around digit 11.

Total comuputation time is 1 623 seconds. Not awesome, especially compared to the Rust solution which can do the same in 30 seconds. But pretty good, all things considered!

Can we do better?

Not with stock Python. I don't know how, anyway; I could micro-optimize some parts, but it would shave off maybe a couple seconds.

But there's no need to stop there. Instead, let's look at Pandas.

Pandas is a data science library, designed to efficiently work with large data sets. Where "efficiently" translates to pretty much like magic. In the first part of the article, we were thinking about doing things in-place, not needlessly reallocating memory, looking for the most space-efficient data structures.

With Pandas, I can just write what I mean and It. Just. Works. Zero hassle.

First, we create a dataframe.

class NonDeterministicALU:
    def __init__(self):
        self.states = pd.DataFrame({
            "x": [0], "y": [0], "z": [0], "w": [0],
            "min": [0], "max": [0]})

The syntax means that we have columns "x", "y", "z", "w", "min", "max", and one row in which all columns are zero. (There are as many rows as the longest list of values passed in. If the lists are not the same length, the columns are padded by None.)

Finding the minimums and maximums for the puzzle answer is super easy:

    def find_puzzle_answer(self):
        zero_states = self.states[self.states["z"] == 0]
        result_min = zero_states["min"].min()
        result_max = zero_states["max"].max()
        return result_min, result_max

The first line selects only those states where z == 0. The other lines take minimum and maximum from the respective columns.

    def execute(self, line):
        if line.startswith("inp"):
            self.execute_input(line)
            return

        # split into instruction, destination register and source
        instr, dest, src = line.split()
        instr_func = INSTRUCTIONS[instr]
        if src in REGISTERS:
            src_col = self.states[src]
            self.states[dest] = instr_func(self.states[dest], src_col)
        else:
            self.states[dest] = instr_func(self.states[dest], int(src))

self.states[dest] is the destination column x, y z or w. There is no iterating over rows. I'm calling a function (like pandas.Series.add) on the whole column at once.

    def expand_states_into(self, dest):
        new_states = []
        for digit in range(1, 10):
            states = self.states.copy()
            states[dest] = digit
            states["min"] = states["min"] * 10 + digit
            states["max"] = states["max"] * 10 + digit
            new_states.append(states)
        self.states = pd.concat(new_states)
        self.states.reset_index(drop=True, inplace=True)

For every digit, I take a copy of the whole state and set the right digit on the copy. Then I just concatenate all the copies together and save the new state. Notice how, again, we can set the whole column at once.

(The reset_index() bit at the end is for bookkeeping: Pandas keeps an "index" for every row, and weird things happen when you concatenate two datasets that have the same indices. I am not using the index anywhere, but calling reset_index() like this has avoided me some problems.)

Finally, the most difficult bit, deduplication:

    def deduplicate(self):
        groups = self.states.groupby(["x", "y", "z", "w"], sort=False)
        self.states = groups.aggregate(
            {"x": "first", "y": "first", "z": "first", "w": "first",
             "min": "min", "max": "max"})
        self.states.reset_index(drop=True, inplace=True)

groupby() works like SQL GROUP BY clause. The result is the data grouped by the selected columns -- i.e., all rows that have the same x, y, z and w will be in the same group.

By default, Pandas will also sort the result, but we can save some time by not doing that.

The aggregate() call will convert each group into a single row -- by taking the first value for the x, y, z and w columns (they're all identical so it doesn't matter which we pick), the minimum of mins, and the maximum of maxs.

Finally, I need to call reset_index(), otherwise the index value is some sort of identifier of the original group, which really messes things up.

That's it (complete source). No messing with dictionaries. I didn't need to iterate over self.states at any point. Every operation can be done via a shorthand.

How's the performance?

=== digit 10 ===
deduplication: 6.851 s
expansion: 1.628 s
continuing with 52907904 states
=== digit 11 ===
deduplication: 21.151 s
expansion: 2.834 s
continuing with 88179840 states
=== digit 12 ===
deduplication: 31.396 s
expansion: 3.462 s
continuing with 101702790 states
=== digit 13 ===
deduplication: 33.273 s
expansion: 2.884 s
continuing with 95866416 states
=== digit 14 ===
deduplication: 34.208 s
expansion: 3.966 s
continuing with 107811162 states
Computation finished in 174.202 s

174 seconds total, almost 10x faster than before. RAM usage peaks around 9 GB, meaning this fits comfortably on my laptop while the browser and vscode is running.

Also, only 10x slower than the best Rust solution before codegen. Considering that this is Python we're talking about, not bad at all.

Conclusion

It is possible to do this in pure Python, with a little trickery. But pure Python really isn't built to handle large datasets. The overhead per item is too large for that.

I took the opportunity to learn a bit of Pandas, and it seems that it is the right tool for this particular job. I will keep it in mind for future Advent of Code puzzles :)
